工業廢氣影響了我們生活和學習的環境。對此，國家頒布相關的法律條文，治理工業廢氣亂排放的現象。一般，VOCs廢氣分為幾種，可溶于水的、刺激性強、惡臭強等類型，其中主要以硫化物、苯類、脂類、烴類等有機廢氣;如果這些毒氣直接排放，不僅會破壞大氣平衡，還會危害周圍生物健康。因此根據廢氣處理的特征進行治理是刻不容緩的，也是亟待解決的，下面吉豐科技就根據VOCs廢氣對環境的污染及處理方法介紹！

Industrial waste gas affects the environment in which we live and study. In response, the country has issued relevant legal provisions to address the phenomenon of indiscriminate discharge of industrial waste gas. Generally, VOCs waste gas can be classified into several types, such as water-soluble, highly irritating, and odorous. Among them, the main organic waste gases are sulfides, benzenes, lipids, hydrocarbons, etc; If these toxic gases are directly emitted, it will not only disrupt the atmospheric balance, but also endanger the health of surrounding organisms. Therefore, it is urgent and urgent to carry out treatment based on the characteristics of exhaust gas treatment. Below, Jifeng Technology will introduce the pollution and treatment methods of VOCs exhaust gas on the environment!

VOCs廢氣對環境污染：

VOCs exhaust gas causes environmental pollution:

廢氣中VOCS的成分主要有二甲苯、四甲苯、醋酸丁酯等，組分比較復雜，且沸點大多比較高（117.6-196.8℃）。VOCs廢氣具有濃度高、污染嚴重，在廢氣治理方面對技術工藝的要求也是非常嚴格的，因此選擇專業的技術方案是非常有必要的。

The main components of VOCs in exhaust gas are xylene, tetramethylbenzene, butyl acetate, etc. The components are relatively complex, and the boiling points are mostly high (117.6-196.8 ℃). VOCs waste gas has high concentration and serious pollution, and the technical requirements for waste gas treatment are also very strict. Therefore, it is necessary to choose a professional technical solution.

VOCs廢氣處理可以用的方法：

Methods that can be used for VOCs waste gas treatment:

1、待處理有機廢氣進入蓄熱室1的陶瓷介質層（該陶瓷介質“貯存”了上一循環的熱量），陶瓷釋放熱量，溫度降低，而有機廢氣吸收熱量，溫度升高，廢氣離開蓄熱室后以較高的溫度進入氧化室，此時廢氣溫度的高低取決于陶瓷體體積、廢氣流速和陶瓷體的幾何結構。

1. The organic waste gas to be treated enters the ceramic medium layer of the heat storage chamber 1 (which "stores" the heat from the previous cycle). The ceramic releases heat and the temperature decreases, while the organic waste gas absorbs heat and the temperature increases. After leaving the heat storage chamber, the waste gas enters the oxidation chamber at a higher temperature. At this time, the temperature of the waste gas depends on the volume of the ceramic body, the flow rate of the waste gas, and the geometric structure of the ceramic body.

2、在氧化室中，有機廢氣再由燃燒器加熱升溫至設定的氧化溫度760℃，使其中的VOC成分分解成二氧化碳和水。由于廢氣已在蓄熱室內預熱，燃料耗量大為減少。氧化室有兩個作用：一是保證廢氣能達到設定的氧化溫度，二是保證有足夠的停留時間使廢氣中VOC充分氧化。 廢氣在氧化室中焚燒，成為凈化的高溫氣體后離開氧化室，進入蓄熱室2（在前面的循環中已被冷卻），放熱降溫后排出，而蓄熱室2吸收大量熱量后升溫（用于下一個循環加熱廢氣）。凈化后的廢氣經煙囪排入大氣，同時引小股凈化氣清掃蓄熱室3。排氣溫度比進氣溫度高40℃左右。

2. In the oxidation chamber, the organic waste gas is heated by the burner to the set oxidation temperature of 760 ℃, causing the VOC components to decompose into carbon dioxide and water. Due to the preheating of exhaust gas in the heat storage chamber, fuel consumption is greatly reduced. The oxidation chamber has two functions: one is to ensure that the exhaust gas can reach the set oxidation temperature, and the other is to ensure sufficient residence time for the VOCs in the exhaust gas to be fully oxidized. The exhaust gas is incinerated in the oxidation chamber and becomes purified high-temperature gas before leaving the oxidation chamber and entering the heat storage chamber 2 (which has been cooled in the previous cycle). After releasing heat and cooling down, it is discharged, while the heat storage chamber 2 absorbs a large amount of heat and heats up (used to heat the exhaust gas in the next cycle). The purified exhaust gas is discharged into the atmosphere through the chimney, while a small stream of purified gas is introduced to clean the heat storage chamber 3. The exhaust temperature is about 40 ℃ higher than the intake temperature.

3、循環完成后，進氣與出氣閥門進行一次切換，進入下一個循環，廢氣由蓄熱室2進入，蓄熱室3排出。同時引回一部分凈化氣清掃蓄熱室1。周而復始，連續工作。

3. After the cycle is completed, the intake and exhaust valves are switched once to enter the next cycle. The exhaust gas enters from the heat storage chamber 2 and is discharged from the heat storage chamber 3. Simultaneously introducing a portion of purified gas to clean the heat storage chamber 1. Repeat the cycle, work continuously.

VOCs廢氣通過廢氣收集裝置，將VOCs廢氣經高壓風機送入RTO系統中加熱，溫度提升后進行高溫氧化分解，形成無毒、無味的高溫煙氣。本設備將燃燒后的高溫煙氣用蜂窩狀陶瓷蓄熱體把熱能回收并儲存，可回收熱量超過95%，用于廢氣預熱，達到環保節能的目的。

VOCs waste gas is collected by a waste gas collection device and sent to the RTO system through a high-pressure fan for heating. After the temperature is raised, it undergoes high-temperature oxidation and decomposition, forming non-toxic and odorless high-temperature flue gas. This device recovers and stores the heat energy from the high-temperature flue gas after combustion using a honeycomb ceramic thermal storage body, with a heat recovery rate of over 95%, which is used for preheating exhaust gas and achieving the goal of environmental protection and energy conservation.
